Perfluorotripropylamine NEW

Shandong Hemao New Materials Co., Ltd

Product Name: CNHM-3283 Electronic Fluorination Liquid (Equivalent to Replacing 3M FC-3283 Brand)

Main technical parameters of CNHM-3283

Project parameters

Clear appearance, colorless

Odor is tasteless

Boiling point 126 ℃

Density (25 ℃) 1.85g/ml

Dielectric constant (1MHz) 2.09

Dielectric strength (2.5mm)>35.7kV

Dielectric loss (1MHz) 0.00029

Surface tension 15.69mN/m

Freezing point -82 ℃

Saturated vapor pressure (20 ℃) 1.516kPa

Critical pressure 4.28MPa

Critical temperature 196.54 ℃

No flash point

Ozone Depletion Potential (ODP) 0

Global Warming Potential (GWP) 108

Specific heat (25 ℃) 1.107 J/(g. K)

Thermal conductivity coefficient (25 ℃) 0.0614W/(m.k)

Latent heat of vaporization 82.8KJ/kg

Kinematic viscosity (25 ℃) 1.376mm2/s

Volume resistivity (25 ℃) ≥ 1 × 1015 Ω. mm

CNHM-3283A Product Features

1. This product has ideal high insulation performance, high density, and high boiling point, and can be widely used in various temperature controlled heat dissipation systems; 2. Non hazardous materials are non flammable and non explosive, with no ignition point or flash point;

3. Good electrical insulation and extremely high breakdown voltage;

4. Low dielectric constant and dielectric loss, without affecting signal transmission;

5. Good fluidity, able to flow and dissipate heat well in the temperature control system;

6. Non toxic, harmless, and non irritating;

7. Environmentally friendly, with an extremely low GWP value and an ODP value of 0, without damaging ozone.

8. Insoluble with water to avoid damage to components caused by moisture.

CNHM-3283 Scope of Application

1. Heat transfer cooling working fluids for semiconductor dry etching, wafer testing, electronic reliability testing, packaging, etc;

2. Various data processing electronic equipment with thermal conductivity and cooling working fluids;

3. Electronic product cleaning agents; Insulation liquid

4. As an intermediate in the synthesis of fluorinated surfactants and other fluorinated chemicals;

5. Intrusive cooling of data center servers.
