BIOTIN-XX-NHS synthesis
- Product Name:BIOTIN-XX-NHS
- CAS Number:89889-52-1
- Molecular formula:C26H41N5O7S
- Molecular Weight:567.7
6066-82-6
744 suppliers
$5.00/10g
72040-64-3
141 suppliers
$25.00/100mg
89889-52-1
107 suppliers
$20.00/5MG
Yield:89889-52-1 71%
Reaction Conditions:
with N-[3-(N,N-dimethylamino)-propyl]-N'-ethyl-carbodiimide hydrochloride in N,N-dimethyl-formamide at 20; for 48 h;
Steps:
2.1 2.1 Biotin-OSu-activated: S2204 (other batches S2223)
The commercial product 6-Biotinylamino-hexanoic acid (Biotin-Ahx-OH, 101 mg, 0.28 mmol) was dissolved in 4 ml of DMF (light suspension). N-hydroxy succinimide (NHS, 36 mg, 0.31 mmol) and N-(3-Dimethylaminopropyl)-N' ethyl-carbodiimide (EDC x HCI, 59 mg, 0.31 mmol.) were added to reaction mixture and stirred at room temperature for 2 days following disappearance of the acid on TLC analysis. Then, the organic solvent was evaporated under high vacuum and the obtained residue was dissolved in CH2CI2 (20 ml) and rapidly washed with 0.1 N HCI solution to remove excess reagents. The combined organic phase were washed with brine (20 ml), dried over anhydrous Na2S04, filtered and concentrated to give a white solid Biotin-OSu activated (91 mg, yield 71 %), used immediately without further purification.
References:
WO2018/188990,2018,A1 Location in patent:Page/Page column 38
